NEMA / IP Rated Boxes

PTS Series Fiberglass Box

The PTS Series of fiberglass boxes provide impact-resistance and durability with a blend of polycarbonate plastic and 10% glass fibers. This combination offers an extremely robust and long-lasting fiberglass-reinforced plastic box that can displace metal enclosures in some cases.  The PTS series fiberglass box also delivers protection against harsh and wet environments and meets the specifications for NEMA 4X and 6 and IP67. Clear covers are available as an option, which allows inspection of the box contents without breaking the seal. Select a model of our PTS series fiberglass-reinforced plastic box.

Filter Models

Fiberglass Box PTS-25301

PTS Series Fiberglass Box
Model # PTS-25301
External Size L x W x D: 2.56" x 1.97" x 2.17"
Internal Size L x W x D: 2.05" x 1.46" x 1.57"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25301-C

PTS Series Fiberglass Box
Model # PTS-25301-C
External Size L x W x D: 2.56" x 1.97" x 2.17"
Internal Size L x W x D: 2.05" x 1.46" x 1.57"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25302

PTS Series Fiberglass Box
Model # PTS-25302
External Size L x W x D: 3.15" x 3.15" x 2.36"
Internal Size L x W x D: 2.44" x 2.44" x 1.77"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25302-C

PTS Series Fiberglass Box
Model # PTS-25302-C
External Size L x W x D: 3.15" x 3.15" x 2.36"
Internal Size L x W x D: 2.44" x 2.44" x 1.77"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25304

PTS Series Fiberglass Box
Model # PTS-25304
External Size L x W x D: 3.94" x 3.94" x 2.95"
Internal Size L x W x D: 2.75" x 2.75" x 2.17"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25304-C

PTS Series Fiberglass Box
Model # PTS-25304-C
External Size L x W x D: 3.94" x 3.94" x 2.95"
Internal Size L x W x D: 2.75" x 2.75" x 2.17"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25308

PTS Series Fiberglass Box
Model # PTS-25308
External Size L x W x D: 4.33" x 3.15" x 2.76"
Internal Size L x W x D: 3.15" x 2.44" x 1.97"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25308-C

PTS Series Fiberglass Box
Model # PTS-25308-C
External Size L x W x D: 4.33" x 3.15" x 2.76"
Internal Size L x W x D: 3.15" x 2.44" x 1.97"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25310

PTS Series Fiberglass Box
Model # PTS-25310
External Size L x W x D: 4.92" x 4.92" x 2.95"
Internal Size L x W x D: 3.54" x 3.53" x 2.17"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25310-C

PTS Series Fiberglass Box
Model # PTS-25310-C
External Size L x W x D: 4.92" x 4.92" x 2.95"
Internal Size L x W x D: 3.54" x 3.53" x 2.17"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25312

PTS Series Fiberglass Box
Model # PTS-25312
External Size L x W x D: 5.12" x 3.15" x 2.76"
Internal Size L x W x D: 4.73" x 2.76" x 1.97"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25312-C

PTS Series Fiberglass Box
Model # PTS-25312-C
External Size L x W x D: 5.12" x 3.15" x 2.76"
Internal Size L x W x D: 4.73" x 2.76" x 1.97"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25315

PTS Series Fiberglass Box
Model # PTS-25315
External Size L x W x D: 5.91" x 5.91" x 3.94"
Internal Size L x W x D: 4.33" x 4.33" x 3.15"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25315-C

PTS Series Fiberglass Box
Model # PTS-25315-C
External Size L x W x D: 5.91" x 5.91" x 3.94"
Internal Size L x W x D: 4.33" x 4.33" x 3.15"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25317

PTS Series Fiberglass Box
Model # PTS-25317
External Size L x W x D: 6.38" x 3.23" x 3.35"
Internal Size L x W x D: 6.02" x 2.87" x 2.76"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25317-C

PTS Series Fiberglass Box
Model # PTS-25317-C
External Size L x W x D: 6.38" x 3.23" x 3.35"
Internal Size L x W x D: 6.02" x 2.87" x 2.76"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25319

PTS Series Fiberglass Box
Model # PTS-25319
External Size L x W x D: 6.69" x 5.51" x 3.74"
Internal Size L x W x D: 6.38" x 5.63" x 2.95"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25319-C

PTS Series Fiberglass Box
Model # PTS-25319-C
External Size L x W x D: 6.69" x 5.51" x 3.74"
Internal Size L x W x D: 6.38" x 5.63" x 2.95"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25323

PTS Series Fiberglass Box
Model # PTS-25323
External Size L x W x D: 7.09" x 3.15" x 3.35"
Internal Size L x W x D: 6.70" x 2.76" x 1.97"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25323-C

PTS Series Fiberglass Box
Model # PTS-25323-C
External Size L x W x D: 7.09" x 3.15" x 3.35"
Internal Size L x W x D: 6.70" x 2.76" x 1.97"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25328

PTS Series Fiberglass Box
Model # PTS-25328
External Size L x W x D: 7.87" x 5.91" x 3.94"
Internal Size L x W x D: 7.45" x 5.48" x 3.15"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25328-C

PTS Series Fiberglass Box
Model # PTS-25328-C
External Size L x W x D: 7.87" x 5.91" x 3.94"
Internal Size L x W x D: 7.45" x 5.48" x 3.15"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25338

PTS Series Fiberglass Box
Model # PTS-25338
External Size L x W x D: 9.84" x 5.91" x 3.94"
Internal Size L x W x D: 9.41" x 5.48" x 3.15"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25338-C

PTS Series Fiberglass Box
Model # PTS-25338-C
External Size L x W x D: 9.84" x 5.91" x 3.94"
Internal Size L x W x D: 9.41" x 5.48" x 3.15"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25340

PTS Series Fiberglass Box
Model # PTS-25340
External Size L x W x D: 11.02" x 7.48" x 5.04"
Internal Size L x W x D: 10.07" x 6.52" x 3.86"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25340-C

PTS Series Fiberglass Box
Model # PTS-25340-C
External Size L x W x D: 11.02" x 7.48" x 5.04"
Internal Size L x W x D: 10.07" x 6.52" x 3.86"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25342

PTS Series Fiberglass Box
Model # PTS-25342
External Size L x W x D: 11.02" x 11.02" x 5.07"
Internal Size L x W x D: 10.07" x 10.07" x 3.86"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25342-C

PTS Series Fiberglass Box
Model # PTS-25342-C
External Size L x W x D: 11.02" x 11.02" x 5.07"
Internal Size L x W x D: 10.07" x 10.07" x 3.86"
Cover Style: Clear, Screw Down Cover

Fiberglass Box PTS-25349

PTS Series Fiberglass Box
Model # PTS-25349
External Size L x W x D: 22.05" x 11.02" x 5.12"
Internal Size L x W x D: 21.09" x 10.07" x 3.86"
Cover Style: Opaque, Screw Down Cover

Fiberglass Box with Clear Cover PTS-25349-C

PTS Series Fiberglass Box
Model # PTS-25349-C
External Size L x W x D: 22.05" x 11.02" x 5.12"
Internal Size L x W x D: 21.09" x 10.07" x 3.86"
Cover Style: Clear, Screw Down Cover
