NEMA / IP Rated Boxes

NBB Series NEMA Box

The NBB Series of NEMA boxes is one of Bud’s most popular enclosures for wet, dirty and/or corrosive environments.. They feature plastic latches and an all-plastic construction. Most of the gasketed enclosures in this series have been tested and approved to UL508-4x specifications, with a few being approved to UL50-4x. All NBB Series enclosures meet IEC529 IP66 requirements.

Filter Models

NEMA Box ABS Poly Blend NBB-10240

NBB Series NEMA Box
Model # NBB-10240
External Size: 5.9" x 5.9" x 3.57"
Internal Size: 5.04" x 5.04" x 3.27"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: ABS Poly Blend
Door Type of Plastic: ABS Poly Blend
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10241

NBB Series NEMA Box
Model # NBB-10241
External Size: 6.79" x 10.73" x 4.33"
Internal Size: 5.9" x 9.84" x 4.07"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: ABS Poly Blend
Door Type of Plastic: ABS Poly Blend
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10243

NBB Series NEMA Box
Model # NBB-10243
External Size: 7.4" x 11.28" x 5.5"
Internal Size: 6.65" x 10.46" x 5.25"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: ABS Poly Blend
Door Type of Plastic: ABS Poly Blend
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10245

NBB Series NEMA Box
Model # NBB-10245
External Size: 13" x 13" x 7.04"
Internal Size: 12.14" x 12.14" x 6.79"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: ABS Poly Blend
Door Type of Plastic: ABS Poly Blend
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10247

NBB Series NEMA Box
Model # NBB-10247
External Size: 11.73" x 15.68" x 6.3"
Internal Size: 10.89" x 14.88" x 6.03"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: ABS Poly Blend
Door Type of Plastic: ABS Poly Blend
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10251

NBB Series NEMA Box
Model # NBB-10251
External Size: 10.55" x 14.52" x 5.9"
Internal Size: 9.76" x 13.74" x 5.64"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: ABS Poly Blend
Door Type of Plastic: ABS Poly Blend
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10253

NBB Series NEMA Box
Model # NBB-10253
External Size: 14.64" x 19.17" x 7.85"
Internal Size: 13.75" x 18.33" x 7.6"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: ABS Poly Blend
Door Type of Plastic: ABS Poly Blend
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10260

NBB Series NEMA Box
Model # NBB-10260
External Size: 5.9" x 5.9" x 3.57"
Internal Size: 5.04" x 5.04" x 3.27"
Cover Style: Clear, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-V0
Type of Plastic: ABS Poly Blend
Door Type of Plastic: Clear Polycarbonate
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10261

NBB Series NEMA Box
Model # NBB-10261
External Size: 6.79" x 10.73" x 4.33"
Internal Size: 5.9" x 9.84" x 4.07"
Cover Style: Clear, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-V0
Type of Plastic: ABS Poly Blend
Door Type of Plastic: Clear Polycarbonate
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10263

NBB Series NEMA Box
Model # NBB-10263
External Size: 7.4" x 11.28" x 5.5"
Internal Size: 6.65" x 10.46" x 5.25"
Cover Style: Clear, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-V0
Type of Plastic: ABS Poly Blend
Door Type of Plastic: Clear Polycarbonate
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10265

NBB Series NEMA Box
Model # NBB-10265
External Size: 13" x 13" x 7.04"
Internal Size: 12.14" x 12.14" x 6.79"
Cover Style: Clear, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-V0
Type of Plastic: ABS Poly Blend
Door Type of Plastic: Clear Polycarbonate
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10267

NBB Series NEMA Box
Model # NBB-10267
External Size: 11.73" x 15.68" x 6.3"
Internal Size: 10.89" x 14.88" x 6.03"
Cover Style: Clear, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-V0
Type of Plastic: ABS Poly Blend
Door Type of Plastic: Clear Polycarbonate
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10271

NBB Series NEMA Box
Model # NBB-10271
External Size: 10.55" x 14.52" x 5.9"
Internal Size: 9.76" x 13.74" x 5.64"
Cover Style: Clear, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-V0
Type of Plastic: ABS Poly Blend
Door Type of Plastic: Clear Polycarbonate
Latch Style: 2 Plastic Latches

NEMA Box ABS Poly Blend NBB-10273

NBB Series NEMA Box
Model # NBB-10273
External Size: 14.64" x 19.17" x 7.85"
Internal Size: 13.75" x 18.33" x 7.6"
Cover Style: Clear, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-V0
Type of Plastic: ABS Poly Blend
Door Type of Plastic: Clear Polycarbonate
Latch Style: 2 Plastic Latches

NEMA Box Poly PTB Blend NBB-15240

NBB Series NEMA Box
Model # NBB-15240
External Size: 5.9" x 5.9" x 3.57"
Internal Size: 5.04" x 5.04" x 3.27"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Outdoor (UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: Poly PTB Blend
Door Type of Plastic: Poly PTB Blend
Latch Style: 2 Plastic Latches

NEMA Box Poly PTB Blend NBB-15243

NBB Series NEMA Box
Model # NBB-15243
External Size: 5.5" x 11.28" x 5.5"
Internal Size: 6.65" x 10.46" x 5.25"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Outdoor (UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: Poly PTB Blend
Door Type of Plastic: Poly PTB Blend
Latch Style: 2 Plastic Latches

NEMA Box Poly PTB Blend NBB-15245

NBB Series NEMA Box
Model # NBB-15245
External Size: 13" x 13" x 7.04"
Internal Size: 12.14" x 12.14" x 6.79"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Outdoor (UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: Poly PTB Blend
Door Type of Plastic: Poly PTB Blend
Latch Style: 2 Plastic Latches

NEMA Box Poly PTB Blend NBB-15247

NBB Series NEMA Box
Model # NBB-15247
External Size: 11.73" x 15.68" x 6.3"
Internal Size: 10.89" x 14.88" x 6.03"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Outdoor (UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: Poly PTB Blend
Door Type of Plastic: Poly PTB Blend
Latch Style: 2 Plastic Latches

NEMA Box Poly PTB Blend NBB-15253

NBB Series NEMA Box
Model # NBB-15253
External Size: 14.64" x 19.17" x 7.85"
Internal Size: 13.75" x 18.33" x 7.6"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Outdoor (UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Type of Plastic: Poly PTB Blend
Door Type of Plastic: Poly PTB Blend
Latch Style: 2 Plastic Latches

NEMA Box Poly PTB Blend NBB-15260

NBB Series NEMA Box
Model # NBB-15260
External Size: 5.9" x 5.9" x 3.57"
Internal Size: 5.04" x 5.04" x 3.27"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Outdoor (UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5A
Type of Plastic: Poly PTB Blend
Door Type of Plastic: Clear Polycarbonate
Latch Style: 2 Plastic Latches

NEMA Box ABS Plastic NBB-22240

NBB Series NEMA Box
Model # NBB-22240
External Size: 5.9" x 5.9" x 3.57"
Internal Size: 5.04" x 5.04" x 3.27"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-HB
Door Flammability Rating: UL94-HB
Type of Plastic: ABS
Door Type of Plastic: ABS
Latch Style: 2 Plastic Latches

NEMA Box ABS Plastic NBB-22241

NBB Series NEMA Box
Model # NBB-22241
External Size: 6.79" x 10.73" x 4.33"
Internal Size: 5.9" x 9.84" x 4.07"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-HB
Door Flammability Rating: UL94-HB
Type of Plastic: ABS
Door Type of Plastic: ABS
Latch Style: 2 Plastic Latches

NEMA Box ABS Plastic NBB-22243

NBB Series NEMA Box
Model # NBB-22243
External Size: 7.4" x 11.28" x 5.5"
Internal Size: 6.65" x 10.46" x 5.25"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-HB
Door Flammability Rating: UL94-HB
Type of Plastic: ABS
Door Type of Plastic: ABS
Latch Style: 2 Plastic Latches

NEMA Box ABS Plastic NBB-22245

NBB Series NEMA Box
Model # NBB-22245
External Size: 13" x 13" x 7.04"
Internal Size: 12.14" x 12.14" x 6.79"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-HB
Door Flammability Rating: UL94-HB
Type of Plastic: ABS
Door Type of Plastic: ABS
Latch Style: 2 Plastic Latches

NEMA Box ABS Plastic NBB-22247

NBB Series NEMA Box
Model # NBB-22247
External Size: 11.73" x 15.68" x 6.3"
Internal Size: 10.89" x 14.88" x 6.03"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-HB
Door Flammability Rating: UL94-HB
Type of Plastic: ABS
Door Type of Plastic: ABS
Latch Style: 2 Plastic Latches

NEMA Box ABS Plastic NBB-22251

NBB Series NEMA Box
Model # NBB-22251
External Size: 10.55" x 14.52" x 5.9"
Internal Size: 9.76" x 13.74" x 5.64"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-HB
Door Flammability Rating: UL94-HB
Type of Plastic: ABS
Door Type of Plastic: ABS
Latch Style: 2 Plastic Latches

NEMA Box ABS Plastic NBB-22253

NBB Series NEMA Box
Model # NBB-22253
External Size: 14.64" x 19.17" x 7.85"
Internal Size: 13.75" x 18.33" x 7.6"
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-HB
Door Flammability Rating: UL94-HB
Type of Plastic: ABS
Door Type of Plastic: ABS
Latch Style: 2 Plastic Latches
