NBA-10148

NEMA Enclosure with Stainless Steel Hinges and Latches NBA-10148
  • NBA Series NEMA Enclosure with Stainless Steel Hinges and Latches

Product Details

Model # NBA-10148 NBA Series Plastic NEMA Enclosure

Gasketed plastic enclosures are useful in wet-washdown, dirty, and corrosive and environments.

See Other Models Search by Size See Accessories Check Stock / Pricing
External Size L x W x D: 15.75" x 11.8" x 7.09"
Internal Size L x W x D: 14.93" x 10.94" x 6.8"
Weight: 4.7 lbs
Color: Light Gray
RoHS Certified: Always Compliant
Service Temperature Max: 70°C
Service Temperature Min: -40°C
Gasket Type: Polyurethane
Type of Plastic: ABS Poly Blend
Door Type of Plastic: ABS Poly Blend
UL Rating: UL508
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-5VA
Cover Style: Opaque, Hinged Cover
Indoor / Outdoor: Indoor (Not UV Stabilized)
Latch Style: Stainless Steel
Mounting Style: Mounting Brackets
NEMA Rating: NEMA 1, NEMA 4, NEMA 4X
IP Rating: 66
hb10148.pdf hb10148.dxf

Drawing
