NBF-32032

NEMA Enclosure ABS Plastic NBF-32032
  • NEMA Plastic Enclosure NBF Series

Product Details

Model # NBF-32032 NBF Series NEMA Box
  • Designed to IP66 of IEC 529 and NEMA 1, 2, 4 and 4x specifications
  • All plastic construction including hinge pins
  • Comes complete with stainless steel wall mounting brackets and hardware
  • Has three plastic latches
  • ABS plastic enclosures are molded out of light gray material with UL94-HB flammability rating. (No UL Label)
See Other Models Search by Size See Accessories Check Stock / Pricing
External Size L x W x D: 19.69" x 15.75" x 6.3"
Internal Size L x W x D: 18.68" x 14.74" x 5.65"
Weight: 9.6 lbs
Color: Light Gray
RoHS Certified: Always Compliant
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-HB
Door Flammability Rating: UL94-HB
Type of Plastic: ABS
Door Type of Plastic: ABS
Service Temperature Min: -40°C
Service Temperature Max: 60°C
IP Rating: 66
Cover Style: Opaque, Hinged Cover
hb32032.pdf hb32032.dxf

Drawing
